• OC Formula Kit
  OC Formula Power Kit
  - 16 Phase CPU Power design + 2 Phase Memory Power design
  - Digi Power (CPU and Memory)
  OC Formula Connector Kit
  - Hi-Density Power Connector
  - 15μ Gold Contact (memory sockets and PCIE x16 slot (PCIE1)
  OC Formula Cooling Kit
  - 12 Layer PCB
  - 2oz copper
  - Heat Pipe Design
• Einzigartige Features
  ASRock USB 3.2 Gen2
  - ASRock Front Panel Type-C USB 3.2 Gen2x2 Header (20 Gb/s)
  - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)
  - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s)
  ASRock Super Alloy
  - XXL Aluminum Alloy Heatsink
  - Premium 90A Power Choke
  - 90A SPS (Smart Power Stage)
  - 50A Dr.MOS
  - Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke)
  - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
  - Shaped PCB Design
  - Matte Black PCB
  - High Density Glass Fabric PCB
  - 12 Layer PCB
  - 2oz Copper PCB
  Server-Grade Low-Loss PCB
  Intel^® 2.5G LAN
  Intel^® 802.11ax WiFi 6E
  ASRock Steel Slots
  ASRock Full Coverage M.2 Heatsink
  ASRock Hyper M.2 (PCIe Gen4x4)
  ASRock POST Status Checker (PSC)
  ASRock Ultra USB Power
  ASRock Status OLED
  ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  ASRock Live Update & APP Shop
• CPU
  - Supports 10th Gen Intel^® Core™ Processors and 11th Gen Intel^® Core™ Processors (LGA1200)
  - Digi Power design
  - 16 Power Phase design
  - Supports Intel^® Turbo Boost Max 3.0 Technology
  - Supports Intel^® K-Series unlocked CPUs
  - Supports ASRock Hyper BCLK Engine III
• Chipsatz
  - Intel^® Z590
• Arbeitsspeicher
  - Dual Channel DDR4 Memory Technology
  - 2 x DDR4 SMD DIMM Slots
  - 11th Gen Intel^® Core™ Processors support DDR4 non-ECC, un-buffered memory up to 6000+(OC)*
  - 10th Gen Intel^® Core™ Processors support DDR4 non-ECC, un-buffered memory up to 5000+(OC)*
  - Supports ECC UDIMM memory modules (operate in non-ECC mode)
  - Max. capacity of system memory: 64GB**
  - Supports Intel^® Extreme Speicherprofile (XMP) 2.0
  - 15μ Gold Contact in DIMM Slots



  *11th Gen Intel^® Core™ (i9/i7/i5) support DDR4 3200 natively; Core™ (i3), Pentium^® and Celeron^® support DDR4 2666 natively.
  10th Gen Intel^® Core™ (i9/i7) support DDR4 2933 natively; Core™ (i5/i3), Pentium^® and Celeron^® support DDR4 2666 natively.

  **Aufgrund von Limitierungen im Betriebssystem ist es möglich, dass Windows^® 32-bit OS weniger als 4 GB RAM für das System reservieren kann. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 2 x 256Mb AMI UEFI Legal BIOS with multilingual GUI support
  - ACPI 6.0 Compliant wake up events
  - SMBIOS 2.7 Support
  - CPU Vcore, DRAM (VCCM, VPPM, VTT), VCCSA, CPU PLL, VCC PLL, STANDBY1, STANDBY2, STANDBY3, VCCIO, VCCIOMEM, PCH Voltage, CPU Internal PLL, Ring PLL, System Agent PLL, Memory Controller PLL Voltage Multi-adjustment
• Grafik
  - n/a
• Audio
  - 7.1 CH HD Audio with Schutz von Inhalten (Realtek ALC1220 Audio Codec)
  - Premium Blu-ray Audio support
  - Supports Surge Protection
  - WIMA Audio Capacitors (For Front Outputs)
  - ESS SABRE9218 DAC for Front Panel Audio (130dB SNR)
  - Pure Power-In
  - Direct Drive Technology
  - PCB Isolate Shielding
  - Impedance Sensing on Rear Out port
  - Individual PCB Layers for R/L Audio Channel
  - Gold Audio Jacks with LED
  - 15μ Gold Audio Connector
  - Nahimic Audio
• LAN
  1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Intel^® I225V)
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE 1 x Gigabit LAN 10/100/1000 Mb/s (Intel^® I219V)
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Drahtloses LAN
  - Intel^® 802.11ax Wi-Fi 6E Module
  - Supports IEEE 802.11a/b/g/n/ax
  - Supports Dual-Band 2x2 160MHz with extended 6GHz band support*
  - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  - Supports Bluetooth 5.2 + High speed class II
  - Supports MU-MIMO



  *Wi-Fi 6E (6GHz band) is not currently enabled by default due to the different regulation status of each country. It will be activated (for supported countries) through Windows^® Update and software update once available. The update is expected to be in the middle of 2021.
• Steckplätze
  11th Gen Intel^® Core™ Processors
  - 3 x PCI Express x16 Slots (PCIE1/PCIE4/PCIE5: single at Gen4x16 (PCIE1); dual at Gen4x8 (PCIE1) / Gen4x8 (PCIE4); triple at Gen4x8 (PCIE1) / Gen4x8 (PCIE4) / Gen3x4 (PCIE5))*
  10th Gen Intel^® Core™ Processors
  - 3 x PCI Express x16 Slots (PCIE1/PCIE4/PCIE5: single at Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE4); triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE4) / Gen3x4 (PCIE5))*

  - 2 x PCI Express 2.0 x1 Slots
  - Supports AMD Quad CrossFireX™, 3-Way CrossFireX™ and CrossFireX™
  - 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ax PCIe WiFi module (on the rear I/O)
  - 15μ Gold Contact in VGA PCIe Slot (PCIE1)



  *Unterstützt NVMe-SSD als Boot-Festplatte
• Speicherplatz
  - 6 x SATA3 6.0 Gb/s Connectors*
  - 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061*
  - 1 x Hyper M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with 11th Gen Intel^® Core™ Processors) or Gen3x4 (32 Gb/s) (with 10th Gen Intel^® Core™ Processors)**
  - 1 x Ultra M.2 Socket (M2_2), unterstützt M.2-Module mit SATA3 (6,0 Gb/s) und M.2-Module mit PCI-Express (Gen3 x4, 32 Gb/s) vom M-Typ 2260/2280.**
  - 1 x Ultra M.2 Socket (M2_3), supports M Key type 2260/2280/22110 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)**



  *M2_2, SATA3_0 and SATA3_1 share lanes. If either one of them is in use, the others will be disabled.
  M2_3, SATA3_4 and SATA3_5 share lanes. If either one of them is in use, the others will be disabled.

  **Supports Intel^® Optane™ Technology (M2_2 and M2_3 only)
  M2_1 supports Intel^® Optane™ Technology only with 10th Gen Intel^® Core™ Processors
  Unterstützt NVMe-SSD als Boot-Festplatte
  Supports ASRock U.2 Kit
• RAID
  - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA Speichergeräte
  - Supports RAID 0 and RAID 1 for M.2 NVMe Speichergeräte*



  *RAID function for PCIe mode SSD in M2_1 is only available with Intel^® SSD installed (with 11th Gen Intel^® Core™ Processors).
• Anschluss
  - 1 x Power LED and Speaker Header
  - 2 x RGB LED Headers*
  - 2 x Addressable LED Headers**
  - 1 x CPU Fan Connector (4-pin)***
  - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
  - 6 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****
  - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
  - 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
  - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card)
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)******
  - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection)
  - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (Supports ESD Protection)
  - 1 x Dr. Debug with LED
  - 1 x Power Button with LED
  - 1 x Reset Button with LED
  - 1 x Retry Button
  - 1 x Safe Boot Button
  - V-Probe™: 2 x 5-set of onboard voltage measurement points laid
  - Rapid OC Buttons: +/- buttons to adjust OC frequency
  - 1 x PCIe ON/OFF Switch
  - 1 x Post Status Checker (PSC)
  - 1 x Slow Mode Switch
  - 1 x LN2 Mode Switch
  - 1 x NickShih's OC Profile 1 Button with LED
  - 1 x NickShih's OC Profile 2 Button with LED
  - 1 x NickShih's OC Profile 3 Button with LED



  *Support in total up to 12V/3A, 36W LED Strip

  **Support in total up to 5V/3A, 15W LED Strip

  ***Der CPU-Lüfteranschluss unterstützt CPU-Lüfter mit einer Leistung von maximal 1 Ampere (12 Watt).

  ****CPU_FAN2/WP_3A supports the water cooler fan of maximum 3A (36W) fan power.

  *****The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.
  CPU_FAN2/WP_3A, CHA_FAN1/WP, CHA_FAN2/WP, CHA_FAN3/WP, CHA_FAN4/WP, CHA_FAN5/WP and CHA_FAN6/WP can auto detect if 3-pin or 4-pin fan is in use.

  ******USB_1 is from ASMedia ASM1074 hub; USB_234 are Intel^® Z590.
• Blende
  - 2 x Antenna Ports
  - 1 x PS/2 Keyboard Port
  - 1 x PS/2 Mouse Port
  - 1 x Optical SPDIF Out Port
  - 3 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (ReDriver) (Supports ESD Protection)*
  - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports ESD Protection)*
  - 4 x USB 3.2 Gen1 Type-A Ports (Supports ESD Protection)*
  - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED)
  - 1 x BIOS Flashback Button
  - 1 x BIOS Selection Switch
  - 1 x Clear CMOS Button
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks with LED)



  *USB3_1 is from Intel^® Z590; USB3_234 are from ASMedia ASM1074 hub.
  Ultra USB Power is supported on USB3_234 port.
  ACPI wake-up function is not supported on USB3_234 port.

  **This motherboard does not support integrated graphics.
• Software und UEFI
  Software
  - ASRock Motherboard Utility (Formula Drive)
  - ASRock Polychrome SYNC*
  UEFI
  - ASRock EZ Mode
  - ASRock Full HD UEFI
  - ASRock My Favorites in UEFI
  - ASRock NickShih's OC Profile
  - ASRock Sofort-Flash
  - ASRock Internet Flash
  - ASRock Easy RAID Installer



  *Diese Tools können im Live Update & APP Shop heruntergeladen werden.
• Support-CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar
• Produktzubehör
  - Quick Installation Guide, Support CD
  - 4 x SATA Data Cables
  - 2 x ASRock WiFi 2.4/5/6 GHz Antennas
  - 1 x ASRock Screwdriver
  - 3 x Screws for M.2 Sockets
  - 3 x Standoffs for M.2 Sockets
• Hardware überwachung
  - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans
  - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, VCCM, VPPM, VCCSA, CPU PLL, VCC PLL, STANDBY1, STANDBY2, STANDBY3, VCCIO, VCCIOMEM, VCCIN AUX Voltage
  - 1 x Status OLED
• Formfaktor
  - EATX Form Factor: 12.0-in x 10.5-in, 30.5 cm x 26.7 cm
  - 12 Layer PCB
  - 2oz Copper PCB
• Betriebssystem
  - Microsoft^® Windows^® 10 64-bit / 11 64-bit
• Zertifizierungen
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)

Die Spezifikationen können ohne vorherigen Hinweis geändert werden. Die Marken und Produktnamen sind Schutzmarken der jeweiligen Firmen. Alle Konfigurationen die von den original Spezifikationen abweichen werden nicht garantiert.

Das oben abgebildete User-Interface ist ein Referenzbeispiel. Das tatsächliche User-Interface kann von der Abbildung abweichen.
